Inertial Measurement Unit ( IMU )
The CS-IM100/200 Inertial Measurement Unit is a 9 degree-of-freedom (DOF) inertial measurement device. The 3-axis accelerometer can be used to sense gravitational acceleration as well as motion. Rotation-rate can be sensed by the 3-axis gyroscope and the magnetometer provides 3-axis measurements of the magnetic field. This calibrated MEMS sensing combination provides a wealth of dynamic measurements to support a wide range of applications. The CS-IMxxx is a cost effective option packaged with a robust housing, interface options, and a simple set up.
Industrial design
CS-IM100/200 has an anodized aluminum case. These sensors are tested to satisfy IP67 certification and can temporarily be immersed in 1 meter depth of water.
Smart data communication
CS-IM100/200 has two LEDs that show the communication status of sensors while receiving data, sending data or computing offline.
Versatile interface
The 6-Pin connectors of CS-IM100/200 are IP67 certified and guarantee the consistency of data communication in harsh environments. Output supported protocols are UART, USB, RS232, RS422, Wireless, & RS485 w/wo multi-drop networked.
CS-IM200 | Inertial Measurement Unit (IMU)
| Power source: 4.1 – 38 VDC | Accelerometer range: ±2 g / ±4 g / ±8 g selectable |
| Output data rate: 1Hz to 2 KHz selectable | Accelerometer in-run bias: <5 µg |
| Data format: ASCII / Binary | Gyroscope range: ±125/250/500/1000/2000 °/s selectable |
| Power consumption: 80 mA (@ 5 V) | Gyroscope angle random walk: 0.35 °/√hr |
| GUI Software: CTi Sensor Connect® | Magnetometer range: ±800 μT |
| Dimension: 1.65” x 2.15” x 1.00” | Magnetometer noise density: 0.06 μT/√Hz |
CS-XX200 Documents | |
 | |
| Product Brief | Datasheet |
| |
| Magnetic sensor calibration guide | |
CS-IM100 | Inertial Measurement Unit (IMU)
| Power source: 4.1 – 38 VDC | Accelerometer range: ±2 g / ±4 g / ±8 g selectable |
| Output data rate: 1Hz to 200 Hz selectable | Accelerometer in-run bias: <10 µg |
| Data format: ASCII / Binary | Gyroscope range: ±250/500/1000/2000 °/s selectable |
| Power consumption: 250 mW (50 mA @ 5 V) | Gyroscope angle random walk: 1.4 °/√hr |
| GUI Software: CTi Sensor Connect® | Magnetometer range: ±800 μT |
| Dimension: 1.65” x 2.15” x 1.00” | Magnetometer noise density: 0.06 μT/√Hz |
CS-XX100 Documents | |
| |
| Product Brief | Datasheet |
| |
| Magnetic sensor calibration guide | |
